Integrating an air-to-water heat pump within a boiler hydronic heating system

ECO^™ Hybrid Dual Fuel Hydronic System

The New ECO™ Hybrid is a dual-fuel hydronic system that integrates our ECO HP air-to-water heat pump with a high-efficiency boiler, providing optimal heating performance. It automatically switches between the heat pump and boiler based on outdoor temperatures to maximize energy efficiency and comfort. Ideal for retrofits and new installations, the ECO HP helps homeowners reduce their carbon footprint and may reduce energy costs while maintaining reliable heat.

Features

Highly Efficient

Achieves efficiencies up to 5.37 COP for optimal savings

Eco-friendly Refrigerant

Heat pump uses R32 refrigerant for improved sustainability

Flexible Applications

Use for radiant heating and domestic hot water

Installation Ready

Easy-Up manifold included and accessory kit available

Optimal Design

Low decibel, quiet operation plus compact design

Cost Savings

Minimal maintenance, rebates and tax credits available in some areas

Locate a contractor Locate a Distributor Product Comparison Tool

See it in action

Technical Specs

Model	Capacity	Efficiency	Power Input	Current Input	Delivery Temp	Outdoor Temp
ECOHP-41	19.04–41.29 MBH	4.96–5.37 COP	1.04–2.44 kW	4.33–25 Amps	77–149 °F	-13–109.4 °F
ECOHP-48	20.2–49.48 MBH	4.60–5.29 COP	1.12–3.15 kW	4.67–26 Amps	77–149 °F	-13–109.4 °F
ECOHP-55	21.94–54.25 MBH	4.50–5.06 COP	1.27–3.53 kW	5.29–27 Amps	77–149 °F	-13–109.4 °F

Type

R-32

Charge

4.04 LBS

Pressure Low Side

377.1 PSIG

Pressure High Side

623.6 PSIG

Type

Rotary

Quantity

Speed

24-92 RPS

Flow

12.1 GPM

Max Temp

149 Deg°F

Piping Conn.

1 Inch

Pressure Drop @ 12.1 rpm

3.9 PSI

ODU Power

208–230/1/6 V/Ph/Hz

ODU Fan Motor

1.3 A

ODU Compressor

26 A

ODU MCA 41/48/55

25/26/27 A

ODU MOPD

30 A

ODU SCCR

5 kA

IDU Power

110-120/1/60 V/Ph/Hz

IDUMCA

1.5 A

IDUMOPD

15 A

IDU Net

69 LBS

IDU Shipping

78 LBS

ODU Net

212 LBS

ODU Shipping

255 LBS

Type

Brushless DC

Quantity

Input

170 W

Speed

200-730 RM

Downloads

Product Manuals

ECO HP IDU Manual ECO HP ODU Manual
